The Height restriction barrier or traffic gantry are mainly used for gate-shaped frames at the entrances of bridges, culverts and tunnels, parking lot or commerical area. They are generally welded steel structures and play the role of protecting bridges, culverts and tunnels. There are signs or LED light on them with the height limit in meters to remind vehicles. The height barrier also can add swing structure to use for paking lot, to allow vehicle access.
Product Description
Height restriction barrier general parameter:
♦Product specifications: customized according to drawing requirements
♦Product material: S235/S355
♦Anti-corrosion treatment: spray painting, hot-dip galvanizing/spraying, etc., according to customer needs
♦Product application: used for installation and setting of special places such as road culvert openings, bridge ends, tunnel openings, rural roads, squares/toll booths/commercial area/residental commuties/parking lot entrances and exits.
1.All the Road sign structure and traffic gantry use international standard steel, the material complies with the provisions of EU standard and the welding procedure specification(WPS) in accordance with EN1090 requirements.
2. Surface coating uses high-quality polyester plastic powder, which is resistant to strong ultraviolet rays, suitable for coastal cities and heavy salt areas, and the average thickness of the plastic layer is not less than 80 microns.
3. The color of the spraying is customer specified.
4. Height Restriction Barrier production procedure: melting active gas shielded welding, AWS ER70S-6 welding wire, indoor welding, reliable welding material quality, crack resistance, and small welding deformation.
5. Service life: more than 30 years.
6. Customization for height barrier: produce according to the drawing that issue by customer or our design institute.
7. Accessories: swing system, ground cage, bolts, nuts, gaskets, wires and cables, etc.
