Traffic signal pole not only including red, green and yellow light signal, also including direction guide, speed guide, monitoring facility and etc.
The traffic light pole can be single arm pole or double arm pole, according to the road wide.
Application usually is urban road crossing and expressways.
Traffic Signal Column General Recommend Parameter
| Pole Recommend Height (m) | 6-7.5M |
| Pole Diameter(mm) | 180-380/240-420 |
| Pole Thickness (mm) | 6/8/10/12/14 |
| Pole Flange(mm) | φ500-φ800 |
| Arm | Single or double |
| Arm Length (m) | 2-20m |
| Arm Diameter (mm) | 100-160/180-380 |
| Arm Thickness (mm) | 4/5/6/8/10 |
Traffic Light Pole Description:
1. Traffic signal column surface coating uses high-quality polyester plastic powder, which is resistant to strong ultraviolet rays, suitable for coastal cities and heavy salt areas, and the average thickness of the plastic layer is not less than 80 microns.
2. Traffic signal pole production procedure: melting active gas shielded welding, AWS ER70S-6 welding wire, indoor welding, reliable welding material quality, crack resistance, and small welding deformation.
3. Traffic light pole production Capability: 5000pcs/month
4. Lifespan: more than 30 years.
5. Road traffic light pole accessories: ground cage, bolts, nuts, gaskets, wires and cables, etc.
Traffic Signal Column Customization:
1. Traffic signal column general characteristics: the pole height, shape and thickness, the arm type, length and thickness, according to your road condition request.
2. Traffic light pole material: Steel S235 and Steel S355.
3. Traffic light pole surface treatment: Hot-dip galvanizing, spraying plastics, and painting. For spraying plastic and painting, thickness and different color can be chosen.
Free design for traffic light pole:
Except the general characteristics, such as dimension and surface color, we can help our customers to design their own products, customers only need to put forward their use needs and provide the local climate and site conditions, we can design the product for free.
Especially For different countries, the weather and seismic data must take into account in the designing to ensure the durability and stability of the traffic signal pole.
International Certificates:
All the traffic light pole use international standard steel, the material complies with the provisions of EU standard and the welding procedure specification (WPS) in accordance with EN1090 requirements.
International certificates: ISO 9001, 1SO14001, ISO45001, EN12899-1, EN1090, and CE.
Traffic Light Pole installation:
The traffic signal pole is installed by base cage, bolt and flange. It is easy-installation and we also can provide the installation guide on request. If you also need us to provide technical team to install on site, it's workable, and we charge only the labor cost.
Traffic Signal Column Maintenance:
The traffic signal column is produced with quality material, meet with outdoor standard, usually no need to make special maintenance, if need special maintenance you can by lift truck.
If request, the traffic signal pole also can add maintenance ladder, line ladder, square ladder or cage ladder available.
